    ZH-S101單節氣缸手持式螺絲機

    智品價
    ¥11000
    市場價
    ¥11000
    規格分類
    ZH-S101
    顏色
    灰白色單通道
    材料
    鋁合金機箱
    配送
    免費配送
    數量
    -
    1
    +
    400-816-6687


    ZH-S101單節氣缸手持式螺絲機Hand-held Screw Machine

    功能特點Functions and characteristics
    1.
    螺絲范圍Screw range:M2-M5。
    2.用的螺絲頭花型如:一字、十字、三角、梅花、內六角、H頭等。
    Screw head pattern for use, such as: word, cross, triangle, plum, hexagon, H head, etc.
    3.
    用的螺絲材料如:鐵、銅、不銹鋼等。Screw materials such as iron, copper, stainless steel, etc.
    4.
    螺絲產品的材料如:塑膠、鐵、鋁等。Materials of screw products, such as plastic, iron, aluminum, etc.
    5.
    效率高,省成本: 鎖付速率可達到0.5秒1顆螺絲,比傳統擰緊效率提高1倍.省1個人。. High efficiency, cost saving: The locking rate can reach 1 screw for 0.5 seconds, which is 1 times higher than the traditional tightening efficiency. Can save 1 man laborer.
    6.
    更輕松,更質保: 左手無需取螺絲,可用于扶住產品;且可保持垂直鎖付,確保鎖付質量。 More relaxed, more quality assurance: The left hand does not need to take the screw, can be used to hold the product; and can maintain vertical lock pay, to ensure the quality of the lock.
    7.
    更清潔,更環保:不再直接接觸螺絲,避免手部接觸造成二次污染而生銹Cleaner, more environmentally friendly: no longer in direct contact with the screws, avoid contact with the hands causing secondary pollution and rust.
    產品規格Product specification



    型號Model

    ZH-S101單節氣缸手持式螺絲機Hand-held screw machine

    ZH-S201雙節氣缸手持式螺絲機Double-section Cylinder Hand-held Screw Machine

    功率Power

    30W

    100W

    輸送距離Delivery Distance

    1-41-4 meters

    0.5-20.5-2 meters

    供料容量Feed Capacity

    標準螺絲3000個Standard screws 3000

    標準螺絲2000個Standard screws 2000

    主要適用的螺絲孔Main screw hole

    沉孔

    平面Plane hole position

    工作氣壓Working Pressure

    4-6KGF/Cm2

    電源Power supply

    220V,50-60HZ

    使用環境Use Environment

    -20-40°C

    批頭選型Batch Selection

    滑套式、根據產品定Sleeve type, bracket type(According to product specification)

    電批選型Electric Batch Type

    標準臺灣奇力速電批 可按客戶要求Standard batch from Taiwan KILEWS(According to customer requirements)

    螺絲規格Screw Specifications

    一字、十字、梅花、內六角、三角、工字型Word, cross, plum, hexagon, triangle, I-shaped

    適用行業Applicable Industry

    通用性強Versatility, basically covers all products

    設備兼容Equipment Compatible

    公差0.5MM、長度5MM Tolerance 0.5MM, length 5MM

    外形尺寸Dimensions

    360*250*195MM





    全部評價0

    儀器售后政策:

    *儀器保修期:一年

    *售后電話:4008166687

    我們提供部分設備的遠程安裝與調試,提供上門安裝維修服務,但收取一定的服務費;有基礎的我公司將免費提供技術指導,由需方調試安裝。


    ?
